| Type-MEA |
|
|
 THE Type-MEA are constructed with metalized polyester film dielectric ,copper-ply wire leads , outer wrapped with polyester film tape and ends sealed with epoxy resin , in non-inductive type.
FEATURES:
■ Indicate flat oval and axial lead .
■ Self-healing property , High stability and reliability.
■ High moisture resistance , Good solder ability.
■ Available on tape and reel for automatic insertion.
APPLICATIONS:
They are ideal for telecommunication equipment's , data processing
industrial instruments , automatic control systems and other general electronic equipment's , equipment's.
SPECIFICATION:
1.Operating temperature : -40℃ ∼ +85℃
2.Capacitance range : .01μF ∼ 18.0μF
3.Capacitance tolerance : J=±5% , K=±10% , M=±20%
4.Rated voltage (RV) : 100 , 250 , 400 , 630VDC.
5.Dissipation factor (DF) : 1.0% max (at 1KHz 25℃)
6.Testing voltage (TV) : 160% of RV for 60sec
7.Insulation resistance (IR) : C≦.33μF and RV≦100vdc ,≧15,000MΩ (at 25℃)
(Measured at RV or 500Vdc C＞.33μF and RV≦100vdc ,≧ 5,000MΩ.μF
whichever is smaller , charge C≦.33μF and RV＞100vdc ,≧30,000MΩ
time 60s) C＞.33μF and RV＞100vdc ,≧10,000MΩ.μF
 |
